DIN100 Series

Summary

Technical specifications

Application

Related products

Download

Back

Summary

Gallery

Video

Product characteristics

Product advantages

Metal casing, compact and shock-resistant structure;

Based on inductive measurement principles, offering high precision, reliability, and stability;

Hollow shaft with a diameter of 20-50mm, suitable for installation in limited spaces;

Stable and controllable autonomous supply.

Technical specifications

System

Electrical

Supply Voltage	5-30V
Signal output method	HTL ( Vout = Vin , 5V = TTL)

Environment

EMC Features	IEC61000-3
Operating Temperature	-40℃~105℃
Humidity	35~90% RH
IP Rating	IP 65
Shock	1,000m/s 2 , sweeping in the X, Y, Z directions, repeated 3 times.
Vibration	10 ~ 500 Hz, vertical amplitude of 2mm or 150m/s 2 , sweeping in the X, Y, Z directions for 11 minutes per sweep, repeated 3 times.
